Platinum Coil Electrode

Electrodes

Product Code: KCE02

This electrode contains a coiled platinum wire fused in a glass tube. This electrode is used as a counter electrode in most of the electrochemical measurements. Platinum coil electrodes are available in two different sizes and compatible with all KLyte electrochemical cell tops.

Ask Quotation

Description

Platinum-coil is made with a platinum wire (O.D. 0.5 mm). Part of the platinum wire is connected with copper wire inside a glass shaft to make an electrical contact. The standard ground-joint 14/23 (KCE02) and 10/18 (KCE03) enables easy assembly and are compatible with all KLyte electrochemical cell-tops. The customized helix diameter, required for any specific application is also available.

Specifications

Technical Specifications

Electrode	KCE02
Material	Pt
Purity	99.95%
Shaft material	Borosilicate glass
Electrode Plug-in-head	Compatible with KLyte banana connector cable (4mm)
Standard Ground Joint sleeve	14/23
Shaft diameter (Top)	12mm
Shaft diameter (Bottom)	6mm
Total Length (approx.)	140mm
Pt wire Length	200mm
O.D. of Pt wire used for	0.5mm
Helix outer diameter	5mm (customizable)
Height of Helix	15mm(customizable)

Downloads

KCE02_KCE03_Pt_Coil.pdf
